Configure your IMPERIAL ZIP 96 Manual Screen Blind

  • Made in France
  • Width: up to 3000mm
  • Height: up to 3000mm
  • Compact housing: 96 x 96mm
  • Fabric: open, semi-open, opaque
  • Operation: by crank handle
  • Thermal and light protection
  • Made to your measurements
*Required step
Your configuration

Factory direct price (incl. tax)

529.42
Instead of 756.32

Final price (tax incl.)
529.42

Summary

My online quote Delivery time pictoDelivered within 8 to 10 weeks*
  • Delivery picto Free
    delivery*
  • Manufacturing picto Custom-
    made
  • Warranty picto Warranty
    5 years*
  • Free Delivery* Free Delivery*
  • Custom manufacturing Custom manufacturing
  • 2-year warranty Garantie
    5 years*
IMPERIAL ZIP 96 Manual Screen Awning for Pergola

Treat yourself to a shaded corner!

The IMPERIAL ZIP Manual Awning by Franciaflex is the ideal solution for creating a shaded corner and protecting yourself from sunlight, wind, or bad weather.

Made in France, the IMPERIAL ZIP fits perfectly on all types of pergolas (aluminum pergolas, bioclimatic, etc.). In addition, its discreet and stylish aluminum housing provides optimal protection for the mechanism and fabric.

Thanks to its one-piece structure, the installation of your awning is made easier. The IMPERIAL ZIP is a pergola awning designed to your measurements and ready to install. Its installation and use are very straightforward and accessible to everyone.

The awning features a manual winch guidance system. Opening and closing the awning is done smoothly using a foldable crank handle.

Diagram of the IMPERIAL ZIP Manual Screen Awning for Pergola

Powder-coated aluminum

Pictogram of the Standard CliKIT White 9016 Gloss color CliKIT White 9016 Gloss
Pictogram of the Standard Color Structured Anthracite Grey 7016 Structured Anthracite Grey 7016
Link to other colorsSee all>
Color of the IMPERIAL ZIP Manual Screen Awning ×

Solar protection fabrics

Pictogram of the 0202 White fabric 0202 White
Pictogram of the 2020 Lin fabric 2020 Lin
Pictogram of the 0101 Grey fabric 0101 Grey
Pictogram of the 3030 Charcoal fabric 3030 Charcoal
Pictogram of the 0606 Bronze fabric 0606 Bronze
Link to other colorsSee all>
Color of the IMPERIAL ZIP Manual Screen Awning ×

Fabric characteristics

UV resistance pictogram UV resistance
Wind resistance pictogram Wind resistance <64km/h
Dimensional stability pictogram Dimensional stability
Easy cleaning pictogram Easy cleaning
See our customers' photos>

An extruded aluminum structure

  • Compact 96x96mm housing in extruded lacquered aluminum, consisting of 2 panels and fitted with a mounting bracket at each end.
  • 2-sided panel in extruded lacquered aluminum providing easy access to the winding mechanism.
  • Pair of lacquered Zamak mounting brackets that clip directly into the rails.
  • Fabric winding system, consisting of a grooved Ø63 galvanized steel tube, mounted on easily retractable counter-flanges.
  • Manual winch guidance system, integrated into the winding tube.
  • Pair of extruded lacquered aluminum lateral guide rails, fitted with a PVC zip guide.
  • 42x26mm extruded lacquered aluminum bottom bar, weighted and fitted at each end with plastic end caps that grip the zip and serve as guides in the rails.
Photo of the Assembly Principle of the IMPERIAL ZIP Awning
My online quote

Custom-designed profiles

  • Rail support bracket of the 96x96mm housing
  • Housing bracket in Zamak to ensure rail guidance
  • Bearing and bearing support assembly ensuring the fixing of the winding tube
  • Upper 96x96mm housing profile with its rail cover panel and its complementary profile that fixes under the housing, between the rails, to contain the fabric in case of strong gusts of wind
  • Solar protection fabric fitted with lateral zips, available in open, semi-opaque, and opaque versions (on request).
  • Ø63 galvanized steel winding tube, operated by a winch guidance system equipped with a folding crank.
  • Zip guide rail with its zip guide, its rail cover panel and its bottom floor stop
  • Bottom bar with its weights and end caps
  • Lower protective profile of the 96x96mm housing
Numbered diagram of the IMPERIAL VIP Awning in exploded view

A zip guidance system for perfect fabric tension

The zip guidance system of the IMPERIAL ZIP Awning allows the rails to ensure the fabric is kept under tension. Fitted with lateral zips, the fabric can be guided along the full height of the awning.

Fitted with 2 half-zippers, this zip system shows very good wind resistance to prevent any flapping or tearing of the fabric. The quality of the fabric is thus preserved, and it retains its taut, wrinkle-free appearance.

Certified Class 5/6 for wind resistance (Standard EN13561), the IMPERIAL ZIP is capable of withstanding winds of up to 64km/h in a free bay depending on your dimensions.

Photo of the zip guidance system of the IMPERIAL ZIP Awning
Close-up on the IMPERIAL ZIP Awning

Product +

  • Housing and frame in powder-coated aluminum
  • Zip guidance in the rails for perfect fabric tension against the elements
  • Strong wind resistance of up to 64km/h in a free bay: class 5/6 (Standard EN13561)
  • Wide choice of micro-ventilated or opaque fabrics for perfect blackout
  • Optimal thermal and light protection contributing to improved energy performance
  • Made to your measurements and ready to install
  • Silent operation

A smart fabric for optimal solar protection!

The MERMET Satiné 5500 fabric offers excellent protection against heat, rejecting up to 96% of solar energy! Thanks to its diagonal satin weave, this fabric provides very good glare control while optimizing natural light input with a clear view to the outside.

Composed of 42% fiberglass and 58% PVC, the Satiné 5500 range guarantees very high resistance to weather conditions as well as discoloration caused by UV rays.

Its dimensional stability ensures optimal tension, in perfect harmony with awnings fitted with zip lateral guide rails. Find out more>

Regarding color, it should be noted that, in general, dark fabrics absorb more heat but reduce glare.

Light-colored fabrics, on the other hand, have the ability to reflect light while maintaining good light transmission.

Example image of MERMET Satiné 5500 solar protection fabrics
My online quote

Side panels and accessories for all seasons!

Would you like to shelter from the sun, wind, rain, or create a private space? No problem, we offer a wide range specially designed to meet all your needs: Screen Awnings, Sliding Glass Curtains, Roof Awnings, Shade Sails, Side Panels... and much more!

Remember to take a look at our must-have accessories to enhance your pergola!

Support resources to assist you

Our technical team remains available and attentive throughout the entire assembly phase of your awning. You will quickly notice the simplicity of the system's installation. It is possible to complete the assembly in just a few hours. Your CliKIT Manual Screen Awning will arrive as a kit with its installation guide.

Link to an online quote

To successfully complete the assembly of your awning, you will need the following tools:

  • Tape measure
  • Phillips screwdriver
  • Spirit level
  • Drill
  • Screwdriver
  • Metal drill bits
  • Hammer

For more information on installation, feel free to view all our documents available to you:

Installation guide pictogramInstallation guide>
User manual pictogramUser manual>
Assembly video pictogramAssembly video>
Photo book pictogramPhoto book>

More than just customer service

You can count on the support of our building experts and enthusiasts to guide you through every step of your journey.

A dedicated technical advisor will work with you to refine your project and best address your requests before and after your order, as well as throughout the entire installation phase.

For any inquiries, do not hesitate to contact our team who will be happy to assist you:

Whether your question is commercial or technical, you can receive all our advice by phone, SMS, video call (FaceTime, WhatsApp) or email.

The CliKIT team
at your service!

Photo of the Sales Director

Olivier Regnier Sales Director

Photo of the Technical Manager

Cédric Cavaillé Technical Manager

Photo of the Logistics Manager

Vanessa Debias Logistics Manager

Photo of the Engineering Manager

Nicolas Font Engineering Manager

Photo of the Technical Advisor

Jérôme Menu Technical Advisor

Photo of the female Technical Advisor

Fiona Rossignol Technical Advisor

My online quote
Manufacturing lead time pictogram

Manufacturing lead time

For more information on manufacturing and delivery lead times*, please consult our page on Delivery Terms>

*The final lead time is only known at the start of production, and may vary depending on the season and factory holiday periods. If you have specific deadlines, it is important to let us know in advance.

Free delivery pictogram

Free delivery

Our kit awnings are delivered by a specialized carrier equipped with a forklift for delivery as close as possible to your installation site.*

Warranties pictogram

Warranties

IMPERIAL ZIP Awnings are guaranteed for 5 years and comply with the strictest European standards. These awnings are part of the Store d'Origine Contrôlée (SOC) quality charter, guaranteeing compliance with standards in force in France (NF), ensuring reduced environmental impact and production from French territory.

The IMPERIAL ZIP benefits from Standard EN13561 and is certified Class 5/6 for wind resistance (depending on dimensions).
