Configure your Motorized Screen Blind IMPERIAL ZIP 96

  • Made in France
  • Width: up to 3800mm
  • Height: up to 3000mm
  • Compact housing: 96 x 96mm
  • Fabric: open weave, semi-open weave, opaque
  • Operation: tubular motorization
  • Thermal and light protection
  • Made to your measurements
*Required step
Your configuration

Factory direct price (incl. tax)

571.84
Instead of 816.91

Final price (tax incl.)
571.84

Summary

My online quote Delivery time pictoLead time: 8 to 10 weeks*
  • Delivery picto Free
    delivery*
  • Manufacturing picto Custom-
    made
  • Warranty picto Warranty
    5 years*
  • Free Delivery* Free Delivery*
  • Custom manufacturing Custom manufacturing
  • 2-year warranty Garantie
    5 years*
Motorized Screen Blind IMPERIAL ZIP 96 for Pergola

Create your own shaded retreat!

The Motorized Blind IMPERIAL ZIP 96 from Franciaflex is the ideal solution to create a shaded area and protect yourself from sunlight, wind or bad weather.

Made in France, the IMPERIAL ZIP fits perfectly on all types of pergolas (aluminum pergolas, bioclimatic, etc.). Furthermore, its discreet and stylish aluminum housing provides optimal protection for the mechanism and fabric.

Thanks to its monoblock structure, the installation of your blind is made easier. The IMPERIAL ZIP is a pergola blind designed to your measurements and ready to install. Its installation and use are very simple and accessible to everyone.

The blind features a high-performance motorized operating system, controllable via a fixed reversing switch or an optional remote control.

Diagram of the Motorized Screen Blind IMPERIAL ZIP for Pergola

Powder-coated aluminum

Picto of Standard Color White CliKIT 9016 Gloss White CliKIT 9016 Gloss
Picto of Standard Color Anthracite Grey 7016 Structured Anthracite Grey 7016 Structured
Link to other ColorsSee all>
Colors of the Manual Screen Blind IMPERIAL ZIP ×

Solar protection fabrics

Picto of Fabric 0202 White 0202 White
Picto of Fabric 2020 Linen 2020 Linen
Picto of Fabric 0101 Grey 0101 Grey
Picto of Fabric 3030 Charcoal 3030 Charcoal
Picto of Fabric 0606 Bronze 0606 Bronze
Link to other ColorsSee all>
Colors of the Manual Screen Blind IMPERIAL ZIP ×

Fabric characteristics

Picto of UV Ray Resistance UV ray resistance
Picto of Wind Resistance Wind resistance up to <64km/h
Picto of Dimensional Stability Dimensional stability
Picto of Easy Cleaning Easy cleaning
See our customers' photos>

An extruded aluminum structure

  • Compact 96x96mm housing in extruded and lacquered aluminum, made up of 2 panels and fitted with a mounting bracket at each end.
  • 2-panel extruded and lacquered aluminum flap providing easy access to the winding mechanism.
  • Pair of lacquered Zamak mounting brackets that snap directly into the channels.
  • Fabric winding system, consisting of a grooved Ø63 galvanized steel tube, mounted on easily retractable counter-flanges.
  • Franciasoft 230 V electric motor housed in the winding tube, available in wired or remote-controlled version (remote control included).
  • Winch with lower travel limiter, integrated into the winding tube.
  • Pair of lacquered extruded aluminum lateral guide channels, fitted with a PVC Zip guide.
  • Charge bar of 42x26mm in extruded lacquered aluminum, weighted and fitted at the ends with plastic end caps that grip the Zip and serve as guides in the channels.
Photo of the Assembly Principle of the Vertical Guide Screen Blind
My online quote

Custom-designed profiles

  • Channel housing support bracket 96x96mm
  • Zamak housing bracket to ensure channel guidance
  • Non-motor side bearing assembly and bearing support ensuring the fixing of the winding tube
  • 96x96mm upper housing profile with its channel flap and its complementary profile that fixes under the housing, between the channels, to contain the fabric in the event of a strong gust of wind
  • Solar protection fabric fitted with lateral zips, available in open weave, semi-opaque, or opaque version (upon request).
  • Ø63 galvanized steel winding tube fitted with a 230V 10Nm motor in wired or remote-controlled version (remote control included)
  • Zip guide channel with its zip guide, its channel flap and its bottom floor stop
  • Charge bar with its weights and charge end caps
  • Lower protection profile of the 96x96mm housing
Numbered exploded view diagram of the IMPERIAL VIP Blind

A zip guide system for perfect fabric tension

The zip guide system of the Vertical Guide Screen Blind allows the channels to keep the fabric under tension. Fitted with lateral zips, the fabric can be guided over the full height of the blind.

Fitted with 2 half-zippers, this zip system demonstrates very good wind resistance to prevent any flapping or tearing of the fabric. The quality of the fabric is thus preserved, and it retains its taut, wrinkle-free appearance.

Certified Class 5/6 for wind resistance (Standard EN13561), the IMPERIAL ZIP is capable of withstanding winds of up to 64km/h in an open bay depending on your dimensions.

Photo of the zip guide system of the Vertical Guide Screen Blind
Close-up on the Vertical Guide Screen Blind

Product +

  • Powder-coated aluminum housing and frame
  • Zip guidance in channels for perfect fabric tension against bad weather
  • High wind resistance of up to 64km/h in an open bay: class 5/6 (Standard EN13561)
  • Wide choice of micro-ventilated or opaque fabrics for perfect blackout
  • Optimal thermal and light protection contributing to improved energy performance
  • Made to your measurements and ready to install
  • Silent operation

A smart fabric for optimal solar protection!

The MERMET Satiné 5500 fabric offers excellent protection against heat, with up to 96% of solar energy rejected! Thanks to its diagonal satin weave, this fabric provides very good glare control while optimizing natural light input with a clear outward view.

Made up of 42% fiberglass and 58% PVC, the Satiné 5500 range guarantees very high resistance to bad weather as well as to discoloration caused by UV rays.

Its dimensional stability ensures optimal tension, in perfect harmony with blinds equipped with lateral zip channels. Learn more>

Regarding colors, it should be noted that, in general, dark fabrics absorb more heat but reduce glare.

On the other hand, light-colored fabrics have the ability to reflect light while maintaining good light transmission.

Sample image of MERMET Satiné 5500 solar protection fabrics

Adjust the brightness with a simple gesture!

The Vertical Guide Screen Blind is equipped with a Franciasoft 230 V electric motorization system integrated into the winding tube, concealed in its aluminum housing. Its nominal power ranges from 10Nm to 20Nm depending on the dimensions of your blind.

The Franciasoft Motor is operated via a fixed reversing switch, or a Franciasoft remote control to benefit from remote adjustment, thanks to the dedicated Well'com technology.

In terms of safety, the IMPERIAL ZIP is equipped with adjustable travel limit switches, as well as an obstacle stop (radio version only) to prevent any accidental damage to the blind.

Please note that the power supply outlet is by default on the right side of the blind when viewed from inside the pergola. It is possible to have the outlet on the opposite side upon request.

Photo of the obstacle stop feature of the Motorized Screen Blind IMPERIAL ZIP
My online quote

Side panels and accessories for all seasons!

Looking to shelter from the sun, wind, rain or create a private space? No problem, we offer a wide range specially designed to meet all your needs: Screen Blinds, Sliding Glass Curtains, Roof Blinds, Shade Sails, Side Panels... and much more!

Don't forget to take a look at our must-have accessories to upgrade your pergola!

Resources to assist you

Our technical team remains available and attentive to you throughout the entire installation phase of your blind. You will quickly notice how simple the installation system is. It is possible to complete the assembly in just a few hours. Your CliKIT Motorized Screen Blind will arrive as a kit with its installation guide.

Link to an online quote

To successfully complete the installation of your blind, you will need the following tools:

  • Tape measure
  • Phillips screwdriver
  • Spirit level
  • Drill
  • Power drill/driver
  • Metal drill bits
  • Hammer

For more information on installation, feel free to view all our documents made available to you:

Picto of the Installation GuideInstallation guide>
Picto of the User ManualUser manual>
Picto of the Assembly VideoAssembly video>
Picto of the Photo BookPhoto book>

More than just a customer service

You can count on the support of our building experts and enthusiasts to guide you throughout every step of your project.

A dedicated technical advisor is assigned to you to refine your project together and best address your requests before and after your order, as well as throughout the entire installation phase.

For any enquiry, do not hesitate to contact our team who will be happy to assist you:

Whether your question is commercial or technical, you can receive all our advice by phone, SMS, video call (FaceTime, WhatsApp) or email.

The CliKIT team
at your service!

Photo of the Sales Director

Olivier Regnier Sales Director

Photo of the Technical Manager

Cédric Cavaillé Technical Manager

Photo of the Logistics Manager

Vanessa Debias Logistics Manager

Photo of the Design Engineer Manager

Nicolas Font Design Engineer Manager

Photo of the Technical Advisor

Jérôme Menu Technical Advisor

Photo of the Female Technical Advisor

Fiona Rossignol Technical Advisor

My online quote
Picto of Manufacturing Lead Time

Manufacturing lead time

For more information on manufacturing and delivery lead times*, please consult our page on Delivery Terms>

*The final lead time is only known once production begins, and may vary depending on the season and factory holiday periods. If you have specific deadlines, it is important to let us know in advance.

Picto of Free Delivery

Free delivery

Our kit blinds are delivered by a specialist carrier equipped with a forklift for delivery as close as possible to your installation site.*

Picto of Warranties

Warranties

IMPERIAL ZIP Blinds are guaranteed for 5 years and comply with the strictest European standards. These blinds are part of the Store d'Origine Contrôlée (SOC) quality charter guaranteeing compliance with standards in force in France (NF), a guarantee of reduced environmental impact and production from French territory.

The IMPERIAL ZIP benefits from Standard EN13561 and is certified Class 5/6 for wind resistance (depending on dimensions).
