IMPERIAL ZIP XL 130 Motorized Screen Awning

Besoin d'un conseil ?

  • -30%
They talk about usChannel logo See> Discover> Watch the video>
Customer
projects
Presentation video picto Presentation
video
Installation guide picto Installation
guide
Customer testimonials picto Customer
testimonials
Delivery terms picto Delivery
terms

Configure your IMPERIAL ZIP XL 130 Motorized Screen Awning

  • Made in France
  • Width: up to 5400mm
  • Height: up to 3000mm
  • Compact box: 130 x 130mm
  • Fabric: open weave, semi-open weave, opaque
  • Operation: tubular motorization
  • Thermal and light protection
  • Made to your measurements
*Required step
Your configuration

Factory direct price (incl. tax)

654.12
Instead of 934.46

Final price (tax incl.)
654.12

Summary

My online quote Delivery time pictoLead time: 8 to 10 weeks*
  • Delivery picto Free
    delivery*
  • Manufacturing picto Custom-
    made
  • Warranty picto Warranty
    5 years*
  • Free Delivery* Free Delivery*
  • Custom manufacturing Custom manufacturing
  • 2-year warranty Garantie
    5 years*
IMPERIAL ZIP XL 130 Motorized Screen Blind for Pergola

Treat yourself to a shaded corner!

The IMPERIAL ZIP XL 130 Motorized Blind from Franciaflex is the ideal solution to create a shaded area and protect yourself from sunlight, wind or bad weather.

Made in France, the IMPERIAL ZIP fits perfectly on all types of pergola (aluminium pergolas, bioclimatic, etc.). In addition, its discreet and stylish aluminium box provides optimal protection for the mechanism and fabric.

Thanks to its one-piece structure, fitting your blind is made easier. The IMPERIAL ZIP is a pergola blind designed to your measurements and ready to install. Its installation and use are very simple and within everyone's reach.

The blind features a high-performance motorized operating system, controllable via a fixed reversing switch or an optional remote control.

Diagram of the IMPERIAL ZIP Motorized Screen Blind for Pergola

Powder-coated aluminium

Icon of the Standard Color CliKIT White 9016 Gloss CliKIT White 9016 Gloss
Icon of the Standard Color Anthracite Grey 7016 Textured Anthracite Grey 7016 Textured
Link to other ColorsSee all>
Colors of the IMPERIAL ZIP Manual Screen Blind ×

Solar protection fabrics

Icon of the 0202 White fabric 0202 White
Icon of the 2020 Linen fabric 2020 Linen
Icon of the 0101 Grey fabric 0101 Grey
Icon of the 3030 Charcoal fabric 3030 Charcoal
Icon of the 0606 Bronze fabric 0606 Bronze
Link to other ColorsSee all>
Colors of the IMPERIAL ZIP Manual Screen Blind ×

Fabric characteristics

UV resistance icon UV resistance
Wind resistance icon Wind resistance <64km/h
Dimensional stability icon Dimensional stability
Easy cleaning icon Easy cleaning
See our customers' photos>

An extruded aluminium structure

  • Compact 130x130mm box in extruded and lacquered aluminium, consisting of 2 panels and fitted with a mounting bracket at each end.
  • Two-sided panel in extruded and lacquered aluminium providing easy access to the winding mechanism.
  • Pair of lacquered Zamak mounting brackets that clip directly into the channels.
  • Fabric winding system, consisting of a grooved Ø63 galvanized steel tube, mounted on easily retractable counter-flanges.
  • Franciasoft 230 V electric motor housed in the winding tube, available in wired or remote-controlled version (remote control included).
  • Winch with lower travel limit stop, integrated into the winding tube.
  • Pair of lateral guide channels in lacquered extruded aluminium, fitted with a PVC zip guide.
  • 42x26mm bottom rail in lacquered extruded aluminium, weighted and fitted at each end with plastic end caps that grip the zip and serve as guides in the channels.
Photo of the Assembly Principle of the IMPERIAL ZIP Blind
My online quote

Custom-designed profiles

  • Channel support side bracket of the 130x130mm box
  • Zamak box bracket to ensure channel guidance
  • Opposite motor bearing assembly and bearing bracket ensuring the fixing of the winding tube
  • Upper 130x130mm box profile with its channel shutter and its complementary profile fixed under the box, between the channels, to contain the fabric in case of strong gusts of wind
  • Solar protection fabric equipped with lateral zips, available in open weave, semi-opaque, opaque versions (upon request).
  • Ø63 galvanized steel winding tube fitted with a 230V 10Nm motor in wired or remote-controlled version (remote control included)
  • Zip guide channel with its zip guide, its channel shutter and its lower floor stop
  • Bottom rail with its weights and end caps
  • Lower protective profile of the 130x130mm box
Numbered exploded-view diagram of the IMPERIAL VIP Screen Blind

A zip guide system for perfect fabric tension

The zip guide system of the IMPERIAL ZIP Blind allows the channels to ensure the fabric is kept under tension. Fitted with lateral zips, the fabric can be guided along the full height of the blind.

Fitted with 2 half-zip fasteners, this zip system shows very good wind resistance to prevent any flapping or tearing of the fabric. The quality of the fabric is thus preserved, and it retains its taut, wrinkle-free appearance.

Certified Class 5/6 for wind resistance (Standard EN13561), the IMPERIAL ZIP can withstand winds of up to 64km/h in open bay depending on your dimensions.

Photo of the zip guide system of the IMPERIAL ZIP Screen Blind
Close-up on the IMPERIAL ZIP Blind

Les + Produit

  • Powder-coated aluminium box and frame
  • Zip guidance in the channels for perfect fabric tension against bad weather
  • Strong wind resistance of up to 64km/h in open bay: class 5/6 (Standard EN13561)
  • Wide choice of micro-ventilated or opaque fabrics for perfect blackout
  • Optimal thermal and light protection contributing to improved energy performance
  • Made to your measurements and ready to install
  • Silent operation

A smart fabric for optimal solar protection!

The MERMET Satiné 5500 fabric offers excellent protection against heat — up to 96% of solar energy is blocked! Thanks to its diagonal satin weave, this fabric provides very good glare control while optimizing natural light with a clear view to the outside.

Composed of 42% fiberglass and 58% PVC, the Satiné 5500 range guarantees very high resistance to bad weather as well as to discoloration caused by UV rays.

Its dimensional stability ensures optimal tension, perfectly suited to blinds fitted with lateral zip channels. Learn more>

Regarding colors, it should be noted that, as a general rule, dark fabrics absorb more heat but reduce glare.

On the other hand, light-colored fabrics have the ability to reflect light while still maintaining good light transmission.

Sample image of MERMET Satiné 5500 solar protection fabric

Adjust the light with a simple gesture!

The IMPERIAL ZIP Blind is fitted with a Franciasoft 230 V electric motorization system integrated into the winding tube and concealed in its aluminium box. Its nominal power ranges from 10Nm to 20Nm depending on the dimensions of your blind.

The Franciasoft Motor is operated via a fixed reversing switch, or a Franciasoft remote control to benefit from remote adjustment, thanks to the dedicated Well'com technology.

In terms of safety, the IMPERIAL ZIP is fitted with adjustable end stops, as well as an obstacle detection stop (radio version only) to prevent any accidental damage to the blind.

For your information, the electrical power supply outlet is by default on the right-hand side of the blind when viewed from inside the pergola. It is possible to have the outlet on the opposite side upon request.

Photo of the obstacle stop feature of the IMPERIAL ZIP Motorized Screen Blind
My online quote

Panels and accessories for all seasons!

Want to shelter from the sun, wind, rain or create a private space? No problem, we offer a wide range specially designed to meet all your needs: Screen Blinds, Sliding Glass Curtains, Roof Blinds, Shade Sails, Side Panels... and much more!

Don't forget to take a look at our essentials to upgrade your pergola!

Resources to assist you

Our technical team remains available and attentive throughout the entire installation phase of your blind. You will quickly notice how simple the installation system is. It is possible to complete the assembly in just a few hours. Your CliKIT Motorized Screen Blind will arrive as a kit with its installation guide.

Link to an online quote

To successfully complete the installation of your blind, you will need the following tools:

  • Tape measure
  • Phillips screwdriver
  • Spirit level
  • Drill
  • Cordless screwdriver
  • Metal drill bits
  • Hammer

For more information on installation, please feel free to view all our documents made available to you:

Installation guide iconInstallation guide>
User manual iconUser manual>
Assembly video iconAssembly video>
Photo Book iconPhoto book>

More than just a customer service

You can count on the support of our experts and building enthusiasts to guide you every step of the way.

A dedicated technical advisor is assigned to you to refine your project together and respond as best as possible to your requests before and after your order, as well as throughout the entire installation phase.

For any enquiry, please do not hesitate to contact our team who will be happy to assist you:

Whether your question is commercial or technical, you can receive all our advice by phone, SMS, video call (FaceTime, WhatsApp) or email.

The CliKIT team
at your service!

Photo of the Sales Director

Olivier Regnier Sales Director

Photo of the Technical Manager

Cédric Cavaillé Technical Manager

Photo of the Logistics Manager (female)

Vanessa Debias Logistics Manager

Photo of the Design Office Manager

Nicolas Font Design Office Manager

Photo of the Technical Advisor (male)

Jérôme Menu Technical Advisor

Photo of the Technical Advisor (female)

Fiona Rossignol Technical Advisor (female)

My online quote
Manufacturing lead time icon

Manufacturing lead time

For more information on manufacturing and delivery lead times*, please visit our page on Delivery Terms>

*The final lead time is only known once production begins, and may vary depending on the season and factory holiday periods. If you have specific deadlines, it is important to let us know in advance.

Free delivery icon

Free delivery

Our kit blinds are delivered by a specialist carrier equipped with a forklift for delivery as close as possible to your installation site.*

Warranties icon

Warranties

IMPERIAL ZIP Blinds come with a 5-year warranty and comply with the strictest European standards. These blinds are part of the Store d'Origine Contrôlée (SOC) quality charter, guaranteeing compliance with current standards in France (NF), ensuring a reduction in environmental impact and production from French territory.

The IMPERIAL ZIP complies with Standard EN13561 and is certified Class 5/6 for wind resistance (depending on dimensions).
