Configure your EOLUX LP Freestanding Bioclimatic Pergola

  • Made in France
  • Width: up to 6000mm
  • Depth: up to 6000mm
  • Roofing: parallel slats
  • Posts: 120 x 120mm
  • Motor: electric actuator with remote control
  • Expandable and customizable pergola
  • Freestanding structure
*Required step
Your configuration

Factory direct price (incl. tax)

6,332.88
Instead of 9,046.97
Final price (tax incl.)
6,332.88

Summary

My online quote Delivery time pictogramLead time: 6 to 8 weeks*
  • Delivery pictogram Free
    delivery*
  • Manufacturing pictogram Custom-
    Made
  • Warranty pictogram 10-year*
    Warranty
  • Free Delivery* Free Delivery*
  • Custom manufacturing Custom manufacturing
  • 2-year warranty Garantie
    10 years*
EOLUX LP Freestanding Bioclimatic Pergola Standard/Custom Parallel Slats Version
Photo of the EOLUX LP Freestanding Bioclimatic Pergola

Finally enjoy your outdoor space!

Would you like to open your living space to the outdoors? The EOLUX LP Freestanding Bioclimatic Pergola is made for you! Equipped with motorized adjustable slats, it will satisfy you in all weather conditions.

Its closed slats protect you from heat or bad weather (rain, snow, etc.). In the semi-open and open position, you benefit from natural ventilation while regulating the light.

The EOLUX Pergola stands out with its design and modern look, perfect for enhancing and adding value to your terrace and home!

Equipped with an electric actuator motor, you can tilt the slats and adjust the light level in the blink of an eye using its remote control.

Available in standard or custom-made version, this bioclimatic pergola model is designed for simple and fast installation. This way, you save up to -50% by assembling it yourself!

Diagram of the EOLUX LP Freestanding Bioclimatic Pergola

Powder-coated aluminum

Standard Color Anthracite Grey 7016 Sanded Anthracite Grey 7016
Slats Pure White 9010
Standard Color Pure White 9010 Matte Pure White 9010 Matte
Slats Pure White 9010
Custom ColorCustom Colors
See all> List of Custom Colors ×

2 Versions depending on your dimensions

1-Module Version pictogram 1-Module Version
2-Module Version pictogram 2-Module Version

Specifications

UV resistance pictogram UV resistance
Wind resistance pictogram Wind resistance
Rain waterproofing pictogram Waterproofing
against rain

A reinforced aluminum structure

  • Structure and slats in powder-coated aluminum with a clean design
  • Partial or total solar light flux regulation, bioclimatic
  • Slat orientation up to 120°, perpendicular to the width of the pergola
  • Double-seal slat assembly using a screw-fixing system
  • Water drainage integrated into the slat support profile
  • 120 x 120mm post with integrated and invisible water drainage
  • Post fixation to the ground by base plate
  • Smooth and silent electric actuator motorization
  • Motorized system controlled by a multi-channel remote control
  • Stainless steel fasteners included
  • Remote-controlled LED lighting strip (optional on request)
  • Wind, rain and temperature weather sensors (optional on request)
Photo of the Assembly Principle of the EOLUX Bioclimatic Pergola
Photo of the Slat Support Profiles and housing Slat support profiles and housing
Photo of the Rafter with integrated water drainage Rafter with integrated water drainage
Photo of the Post with invisible water drainage Post with invisible water drainage
Photo of Aluminum Slats with sealing gasket Aluminum slats with sealing gasket

Adjustable slats, just the way you like!

Made from lacquered extruded aluminum, each adjustable slat measures 167mm wide with a thickness of 40mm. In the closed position, the double seals with which they are equipped ensure a perfect waterproof seal.

Furthermore, a drainage system channels water towards a downpipe integrated into the post. In the closed position, the slats form an apron that drains rainwater. Each slat is fitted with a gutter that flows discreetly from the gutter rail towards the post.

The rounded profile of each slat helps reduce the noise impact of rain on your pergola.

Photo of the adjustable slats of the EOLUX Bioclimatic Pergola

Made from very high quality aluminum, its French-manufactured structure demonstrates great robustness while combining lightweight properties, specially designed to offer the best resistance against multiple weather events.

To fully enjoy your living space without worrying about weather conditions, the EOLUX Bioclimatic Pergola innovates with its adjustable slats, allowing you to spend time on your terrace in any season.

Diagram of a Bioclimatic Pergola with its slats closed in the rain Closed slats to protect from bad weather (rain, snow, etc.)
Diagram of a Bioclimatic Pergola with its slats closed in the sun Closed slats to protect from the sun's UV rays
Diagram of a Bioclimatic Pergola with its slats open with an air current Open slats to enjoy the sun with optimal ventilation
Diagram of a Bioclimatic Pergola with its slats partially open for natural ventilation Partially open slats for natural ventilation while regulating light

Adjust the light level with a single click!

The slat orientation is managed by an actuator motor that ensures optimal smoothness and precision. Silent, the motor actuator is positioned at the rear of the pergola facade for greater discretion, behind an aluminum cover provided for this purpose.

This motorized system is controlled by a 6-channel remote control to adjust the slat tilt remotely. These channels allow you to create scenarios: you can control the front slats on one channel, the rear slats on another, and all slats together on a third channel. With the LED option, your remote control can also manage the lighting.

Photo of the EOLUX Bioclimatic Pergola and its magnetic crank handle

Add color to your evenings!

An LED Light Strip can be discreetly integrated into the beams to provide lighting across the entire surface of the pergola. This LED lighting diffuses an indirect and pleasant light that will allow you to extend your evenings under your terrace according to the ambiance you prefer!

This LED lighting option has a power output of 1270 lumens at 4000K and a consumption of 14.4W / meter for optimal and energy-efficient brightness, day and night.

The LED Lighting option is available on simple request.

Photo of the LED option for the EOLUX Bioclimatic Pergola
Photo of the LED option with orange lighting Orange ambiance
Photo of the LED option with green lighting Green ambiance
Photo of the LED option with blue lighting Blue ambiance
Photo of the LED option with pink lighting Pink ambiance
My online quote

Weather sensors available on request

No longer fear weather uncertainties under your pergola thanks to the various weather sensors connected to the motorized adjustable slat system, available as an option on request.

Stay dry with the Rain Sensor RAIN102H which will trigger the complete closing of the slats at the first sign of a shower.

The Wind Sensor ANEM4 allows the slats to partially open in the event of a gust to let air circulate without applying pressure to the structure.

In the event of frost, the Temperature Sensor TPMP150 can command the temporary locking of the automatic slat operation to prevent any potential damage until temperatures become milder.

Photo of weather sensors on the EOLUX Bioclimatic Pergola
Weather sensor introduction pictogram
Photo of the Rain Sensor Rain Sensor RAIN102H
Photo of the Wind Sensor Wind Sensor ANEM4
Photo of the Temperature Sensor Temperature Sensor TPMP150

An expandable and customizable pergola throughout the seasons!

CliKIT develops the concept of an Expandable Pergola to adapt as closely as possible to your wishes or your current budget. Rest assured that in the near or distant future, your pergola remains in perpetual evolution!

Would you like to shelter from the sun, wind, rain or delimit a private space? No problem, we offer you a wide range specially designed to meet all your expectations: Screen Blinds, Sliding Glass Curtains, Roof Blinds, Shade Sails, Side Panels... and much more!

Be sure to take a look at our must-have accessories to upgrade your pergola!

Photo of Glass Curtains for Pergola Glass Curtains
Photo of Blinds and Shade Sails for Pergola Blinds & Shade Sails
Photo of Side Panels for Pergola Side Panels

Resources to assist you

Our technical team remains available and attentive to you throughout the entire assembly phase of your pergola. You will quickly notice how simple the installation system is. It is possible to complete the assembly in just a few hours. Your CliKIT pergola will arrive as a kit containing the aluminum structure and roofing elements, accessories, as well as the installation guide.

Link to an online quote

To successfully complete the assembly of your pergola, you will need the tools listed below:

  • Allen key set (3, 4, 5 and 6)
  • PH2 cross-head bit
  • Torx AW20 bit
  • Utility knife
  • Caulking gun
  • Drill
  • Clutch screwdriver
  • Ø 8mm socket
  • Drill bits according to floor and wall fixings
  • 13mm open-end wrench
  • Spirit level
  • Rubber mallet
  • Sawhorse or trestles

For more information on installation, feel free to view all our documents available to you:

Installation Guide pictogramInstallation Guide>

More than just a customer service

You can count on the support of our construction experts and enthusiasts to accompany you throughout all your steps.

A dedicated technical advisor works with you to refine your project and best meet your needs before and after your order, as well as throughout the entire assembly phase.

For any enquiry, do not hesitate to contact our team who will be happy to assist you:

Whether your question is commercial or technical, you can receive all our advice by phone, SMS, video call (FaceTime, WhatsApp) or email.

The CliKIT
team is here for you!

Photo of the Sales Director

Olivier Regnier Sales Director

Photo of the Technical Manager

Cédric Cavaillé Technical Manager

Photo of the Logistics Manager (female)

Vanessa Debias Logistics Manager

Photo of the Engineering Manager

Nicolas Font Engineering Manager

Photo of the Technical Advisor (male)

Jérôme Menu Technical Advisor

Photo of the Technical Advisor (female)

Fiona Rossignol Technical Advisor (female)

My online quote
Manufacturing lead time pictogram

Manufacturing lead time

For more information regarding manufacturing and delivery lead times*, please consult our page on Delivery Terms>

*The final lead time is only known at the time of production and may vary depending on the season and factory holiday periods. If you have specific deadlines, it is important to let us know in advance.

French flag pictogram

Made in France

Free delivery pictogram

Free delivery

Our bioclimatic pergolas in kit form are delivered by a specialist carrier equipped with a forklift for delivery as close as possible to your installation site.*

  • Free delivery from €1,500 incl. VAT in mainland France, Belgium, Germany, Austria, the Netherlands, Luxembourg
  • Delivery to other European countries: on request
  • Transport package for Paris intra-muros: €192 incl. VAT
  • Transport package for high mountain regions with difficult access: €240 incl. VAT
  • Transport package for the Breton islands: on request
  • Transport package for Corsica: €690 incl. VAT
  • Transport and customs documentation package for Switzerland: €483 excl. VAT**
  • Transport package for Monaco: on request

*subject to access conditions for forklift and articulated lorry. It is important to notify us of any potential access issues. **Swiss customs duties and VAT remain the responsibility of the recipient.

Delivery country flags icon
  • Free delivery from €1,500 incl. VAT in mainland France, Belgium, Germany, Austria, the Netherlands, Luxembourg
  • Delivery to other European countries: on request
  • Transport package for Paris intra-muros: €192 incl. VAT
  • Transport package for hard-to-reach high mountain regions: €240 incl. VAT
  • Transport package for the Breton islands: on request
  • Transport package for Corsica: €690 incl. VAT
  • Transport package and customs documents for Switzerland: €483 excl. VAT**
  • Transport package for Monaco: on request

*subject to access conditions by forklift and semi-trailer. It is important to notify us of any potential access issues. **customs duties and Swiss VAT remain the responsibility of the recipient.

Pictogram of delivery country flags
Warranties pictogram

Warranties

Our bioclimatic pergolas are designed to meet the strictest European standards, guaranteeing optimal manufacturing quality, durability and reliability. All aluminum profiles benefit from QUALICOAT-certified powder coating, a guarantee of excellent resistance to UV rays, bad weather and corrosion, for a long-lasting finish over time.

Manufacturer warranties

    • Aluminum structure and powder coating: 10 years. Warranty against manufacturing defects in the structure and its powder-coated finish.
    • Wear parts: 2 years. This warranty covers in particular electrical equipment (motor, actuator, electronics) as well as slat seals.
    • LED lighting kit: 2 years. Warranty on the components of the lighting system.

These warranties reflect the manufacturer's commitment to offering products that combine performance, longevity and manufacturing quality.
